Nom Voltage(V) 12
Nom Capacity (AH) 20/10/5hr rate 7.2/7.2/6.12
Weight 5.91 (2678kg)
Length 5.94" (151mm)
Width 2.56" (65mm)
Height 3.70" (94mm)
Terminal Height 4.02" (102mm)
Terminal Type / Position F1 / 5
Max discharge current (A) 5 sec 36
Ambient Temp Charge 32°F - 104°F
Discharge -4°F - 122°F
Storage -4°F - 104°F
Max Charge Current 2.16
Replaces:
- SmartUPS 250 (BP7-12T1)
- SmartUPS 400 (BP7-12T1)
- SmartUPS 420 (BP7-12T1)
- SmartUPS 450 (BP7-12T1)
- SmartUPS 600 (BP7-12T1)
- SmartUPS 700 (BP7-12T1)
- SmartUPS 1000R2BX120 (BP7-12T1)
- SmartUPS 1000RM2U (BP7-12T1)
- SmartUPS 1000RMNET (BP7-12T1)
- SmartUPS 1000RMUS (BP7-12T1)
- SmartUPS 1400RM (BP7-12T1)
- SmartUPS 1400RMNET (BP7-12T1)
- SmartUPS 2200RM (BP7-12T1)
- SmartUPS 2200RM3U (BP7-12T1)
- SmartUPS 2200RMI3U (BP7-12T1)
- SmartUPS 3000RM3U (BP7-12T1)
- SmartUPS 3000RMI3U (BP7-12T1)
- SmartUPS 3000RMT3U (BP7-12T1)
- SmartUPS 420NET (BP7-12T1)
- SmartUPS 450Net (BP7-12T1)
- SmartUPS 5000RMT5U (BP7-12T1)
- SmartUPS 5000RMT5UXFMR (BP7-12T1)
- SmartUPS 5000RMTXFMR (BP7-12T1)
- SmartUPS 5000T (BP7-12T1)
- SmartUPS 5000TXFMR (BP7-12T1)
- SmartUPS 600LS (BP7-12T1)
- SmartUPS 700BX120 (BP7-12T1)
- SmartUPS 700NET (BP7-12T1)
- SmartUPS 700RM (BP7-12T1)
- SmartUPS 700RMNet (BP7-12T1)
- SmartUPS 700X93 (BP7-12T1)
- SmartUPS A1000RM2U (BP7-12T1)
- SmartUPS SP500DR (BP7-12T1)
- SmartUPS SU1000 RACK EXTENDED (BP7-12T1)
- SmartUPS SU1400RM (RACK) (BP7-12T1)
- SmartUPS SU360SX (BP7-12T1)
- SmartUPS SU420NET (BP7-12T1)
- SmartUPS SU450 (BP7-12T1)
- SmartUPS SU450NET (BP7-12T1)
- SmartUPS SU5000T (BP7-12T1)
- SmartUPS SU5000TX168 (BP7-12T1)
- SmartUPS SU5000TXFMR (BP7-12T1)
- SmartUPS SU600 (BP7-12T1)
- SmartUPS SU600LS (BP7-12T1)
- SmartUPS SU700 (BP7-12T1)
- SmartUPS SU700BX120 (BP7-12T1)
- SmartUPS SU700NET (BP7-12T1)
- SmartUPS SU700X167 (BP7-12T1)
- SmartUPS SU700X93 (BP7-12T1)
- SmartUPS SUVS420 (BP7-12T1)
- SmartUPS VS420 (BP7-12T1)
- SmartUPS RM SU1400RM (BP7-12T1)
- SmartUPS RM SU1400RMBX120 (34) (BP7-12T1)
- SmartUPS RM SU1400RMNET (BP7-12T1)
- SmartUPS RM SU1400RMX106 (BP7-12T1)
- SmartUPS RM SU1400RMX176 (BP7-12T1)
- SmartUPS RM SU1400RMX93 (BP7-12T1)
- SmartUPS RM SU1500RMX155 (BP7-12T1)
- SmartUPS RM SU1500RMXLX157 (BP7-12T1)
- SmartUPS RM SU2000R3X155 (BP7-12T1)
- SmartUPS RM SU2000RMXLX157 (BP7-12T1)
- SmartUPS RM SU2200R3BX120 (BP7-12T1)
- SmartUPS RM SU2200R3X106 (BP7-12T1)
- SmartUPS RM SU2200R3X147 (BP7-12T1)
- SmartUPS RM SU2200R3X152 (BP7-12T1)
- SmartUPS RM SU2200R3X167 (BP7-12T1)
- SmartUPS RM SU2200RM3U (BP7-12T1)
- SmartUPS RM SU2200RMXL3U (BP7-12T1)
- SmartUPS RM SU3000R3BX120 (BP7-12T1)
- SmartUPS RM SU3000R3X145 (BP7-12T1)
- SmartUPS RM SU3000RM3U (BP7-12T1)
- SmartUPS RM SU3000RMT3U (BP7-12T1)
- SmartUPS RM SU3000RMTX136 (BP7-12T1)
- SmartUPS RM SU5000R5TBX120 (BP7-12T1)
- SmartUPS RM SU5000R5XLTXFMR (BP7-12T1)
- SmartUPS RM SU5000RMT5U (BP7-12T1)
- SmartUPS RM SU5000RMT5UXFMR (BP7-12T1)
- SmartUPS RM SU5000RMTSU & AP9621 (BP7-12T1)
- SmartUPS RM SU700RM (BP7-12T1)
- SmartUPS RM SU700RMNET (BP7-12T1)
- BackUPS 300 (BP7-12T1)
- BackUPS 400 (BP7-12T1)
- BackUPS 200 - 1 battery version (BP7-12T1)
- BackUPS 200 - 2 battery version (BP7-12T1)
- BackUPS 200B - 1 battery version (BP7-12T1)
- BackUPS 200B - 2 battery version (BP7-12T1)
- BackUPS 250B (BP7-12T1)
- BackUPS 280B (BP7-12T1)
- BackUPS 400B (BP7-12T1)
- BackUPS 500M (BP7-12T1)
- BackUPS 500MC (BP7-12T1)
- BackUPS 700UC (BP7-12T1)
- BackUPS BK1250B (BP7-12T1)
- BackUPS BK200 (BP7-12T1)
- BackUPS BK200B (BP7-12T1)
- BackUPS BK200C (BP7-12T1)
- BackUPS BK250 (BP7-12T1)
- BackUPS BK250B (BP7-12T1)
- BackUPS BK280B (BP7-12T1)
- BackUPS BK300 (BP7-12T1)
- BackUPS BK300C (BP7-12T1)
- BackUPS BK300X116 (BP7-12T1)
- BackUPS BK300XIII (BP7-12T1)
- BackUPS BK350 (BP7-12T1)
- BackUPS BK350E1 (BP7-12T1)
- BackUPS BK400 (BP7-12T1)
- BackUPS BK400B (BP7-12T1)
- BackUPS BK500 (BP7-12T1)
- BackUPS BK500MC (BP7-12T1)
- BackUPS CS350 (BP7-12T1)
- BackUPS CS500 (BP7-12T1)
- BackUPS CS BK350 (BP7-12T1)
- BackUPS CS BK350E1 (BP7-12T1)
- BackUPS CS BK500 (BP7-12T1)
- BackUPS CS BK500EI (BP7-12T1)
- BackUPS LS BP420S (BP7-12T1)
- BackUPS LS BP500CLR (BP7-12T1)
- BackUPS LS BP500UC (BP7-12T1)
- BackUPS LS BP600 (BP7-12T1)
- BackUPS Office 400 (BP7-12T1)
- BackUPS PRO 280 (BP7-12T1)
- BackUPS PRO 420 (BP7-12T1)
- BackUPS PRO 280BPNP (BP7-12T1)
- BackUPS PRO 280C (BP7-12T1)
- BackUPS PRO 280PNP (BP7-12T1)
- BackUPS PRO 280S (BP7-12T1)
- BackUPS PRO 350U (BP7-12T1)
- BackUPS PRO 420C (BP7-12T1)
- BackUPS PRO 420PNP (BP7-12T1)
- BackUPS PRO 420S (BP7-12T1)
- BackUPS PRO 500CLR (BP7-12T1)
- BackUPS PRO 500U (BP7-12T1)
- BackUPS PRO BP280 (BP7-12T1)
- BackUPS PRO BP280C (BP7-12T1)
- BackUPS PRO BP280IPNP (BP7-12T1)
- BackUPS PRO BP280PNP (BP7-12T1)
- BackUPS PRO BP280S (BP7-12T1)
- BackUPS PRO BP280SUS (BP7-12T1)
- BackUPS PRO BP280SX116 (BP7-12T1)
- BackUPS PRO BP420 (BP7-12T1)
- BackUPS PRO BP420C (BP7-12T1)
- BackUPS PRO BP420IPNP (BP7-12T1)
- BackUPS PRO BP420PNP (BP7-12T1)
- BackUPS PRO BP420S (BP7-12T1)
- BackUPS PRO BP420SUS (BP7-12T1)
- BackUPS PRO USB BP350UC (BP7-12T1)
- BackUPS PRO USB BP500CLR (BP7-12T1)
- BackUPS PRO USB BP500UC (BP7-12T1)
- APC AP330 (BP7-12T1)
- APC AP330XT+ (BP7-12T1)
- APC AP360 (BP7-12T1)
- APC AP360SX (BP7-12T1)
- APC AP600 (BP7-12T1)
- APC Dell SmartUPS 2200RM3U (BP7-12T1)
- APC Dell SmartUPS 2200RMI3U (BP7-12T1)
- APC Dell SmartUPS 3000RM3U (BP7-12T1)
- APC Dell SmartUPS 3000RMI3U (BP7-12T1)
- APC Personal Powercell (BP7-12T1)
- APC PowerCell Personal (BP7-12T1)
- APC Pro 350 USB (BP7-12T1)
- APC Professional PowerCell (BP7-12T1)
