Nom Voltage(V) 6
Nom Capacity (AH) 20/10/5hr rate 4.5/4.5/3.825
Weight 2 (908kg)
Length 2.76" (70mm)
Width 1.85" (47mm)
Height 3.98" (101mm)
Terminal Height 4.21" (107mm)
Terminal Type / Position F1 / 1
Max discharge current (A) 5 sec 22.5
Ambient Temp Charge 32°F - 104°F
Discharge -4°F - 122°F
Storage -4°F - 104°F
Max Charge Current 1.35
Replaces:
- APC AP200 (BP5-6)
- BackUPS 250 (BP5-6)
- SmartUPS SU250 (BP5-6)
- SmartUPS SU370 (BP5-6)
- SmartUPS SU400 (BP5-6)
